Made from cross-linked polyolefin compounds, the high anti-tracking properties of the products provide max operational reliability. Used to provide insulation protection for cable terminal, joint, ect.
| Property | Typical data |
|---|---|
| Hardness | 85(Shore A) |
| Tensile strength | 12Mpa |
| Elongation at break | 4 |
| Volume resistance | 1×10¹⁴Ω.cm |
| Dielectric strength | ≥20KV/mm |
| Dielectric constant | <2.5ε |
| Shrink temperature | 120‑140℃ |
| Shrink ration (dia) | 2.5 |
| Longitudinal shrinkage | ±5% |
| Oxygen index | 27ox |
| Specification | Befor shrinkable(Dia of inside) | After shrinkable(Dia of inside) | Wall thickness after shrinkable | Length | Color |
|---|---|---|---|---|---|
| JY1‑10/4 | >10 | ≤4 | 2.4±0.1 | 1000 | Black、Red、Green、Blue、Yellow |
| JY1‑15/6 | >15 | ≤6 | 2.4±0.1 | Black、Red、Green、Blue、Yellow | |
| JY1‑20/8 | >20 | ≤8 | 2.4±0.1 | Black、Red、Green、Blue、Yellow | |
| JY1‑30/10 | >30 | ≤10 | 2.4±0.1 | Black、Red、Green、Blue、Yellow | |
| JY1‑35/12 | >35 | ≤12 | 2.4±0.1 | Black、Red、Green、Blue、Yellow | |
| JY1‑40/14 | >40 | ≤14 | 2.4±0.1 | Black、Red、Green、Blue、Yellow | |
| JY10‑30/12 | 30±1 | ≤12 | 2.6±0.1 | Red | |
| JY10‑35/15 | 35±1 | ≤15 | 2.6±0.1 | Red | |
| JY10‑40/18 | 40±1 | ≤18 | 2.6±0.1 | Red | |
| JY10‑50/20 | 50±1 | ≤20 | 2.6±0.1 | Red | |
| JY35‑50/20 | 50±1 | ≤20 | 3.3±0.1 | Red | |
| JY35‑60/25 | 60±1 | ≤25 | 3.3±0.1 | Red | |
| JY35‑70/30 | 70±1 | ≤30 | 3.3±0.1 | Red | |
| JY35‑75/35 | 75±1 | ≤35 | 3.3±0.1 | Red |
Dimension(mm)
