Suitable for 6/10kV, 8.7/10kV, XLPE insulated Single Core, Three Cores power cables.
| Test item | Parameter |
|---|---|
| Wet Power Frequency Withstand Voltage Test (Outdoor) | 35kV/1min |
| Dry Power Frequency Withstand Voltage Test (Indoor) | 39kV/5min |
| Impact Pressure Test | 95kV 1.2/50μs+10 times |
| Partial Discharge Test | ≤10pc（1.73Uo) |
| Product Name | Item Code | Applicable Cable Section(m㎡) |
|---|---|---|
| Single Core Indoor Termination | NSY-10/1.1 | 25-50 |
| NSY-10/1.2 | 70-120 | |
| NSY-10/1.3 | 150-240 | |
| NSY-10/1.4 | 300-500 | |
| Single Core Outdoor Termination | WSY-10/1.1 | 25-50 |
| WSY-10/1.2 | 70-120 | |
| WSY-10/1.3 | 150-240 | |
| WSY-10/1.4 | 300-500 | |
| Single Core Straight Joint | JSY-10/1.1 | 25-50 |
| JSY-10/1.2 | 70-120 | |
| JSY-10/1.3 | 150-240 | |
| JSY-10/1.4 | 300-500 | |
| Three Cores Indoor Termination | NSY-10/3.1 | 25-50 |
| NSY-10/3.2 | 70-120 | |
| NSY-10/3.3 | 150-240 | |
| NSY-10/3.4 | 300-500 | |
| Three Cores Outdoor Termination | WSY-10/3.1 | 25-50 |
| WSY-10/3.2 | 70-120 | |
| WSY-10/3.3 | 150-240 | |
| WSY-10/3.4 | 300-500 | |
| Three Cores Straight Joint | JSY-10/3.1 | 25-50 |
| JSY-10/3.2 | 70-120 | |
| JSY-10/3.3 | 150-240 | |
| JSY-10/3.4 | 300-500 | |
| Three Cores Indoor Oil Immersion Termination | NSZ-10/3.1 | 25-50 |
| NSZ-10/3.2 | 70-120 | |
| NSZ-10/3.3 | 150-240 | |
| NSZ-10/3.4 | 300-500 | |
| Three Cores Outdoor Oil Immersion Termination | WSZ-10/3.1 | 25-50 |
| WSZ-10/3.2 | 70-120 | |
| WSZ-10/3.3 | 150-240 | |
| WSZ-10/3.4 | 300-500 | |
| Three Cores Oil Immersion Straight Joint | JSZ-10/3.1 | 25-50 |
| JSZ-10/3.2 | 70-120 | |
| JSZ-10/3.3 | 150-240 | |
| JSZ-10/3.4 | 300-500 | |
