Applications:
Primary electrical insulation and waterproof for busbar connections up to 35KV.
Features:
Excellent waterproof properties
Flexible to fill any irregular shapes
Anti-aging
Service temperature: -30°C to 80°C
Standard color: Black
| Property | Testing method | Typical data |
|---|---|---|
| Tensile strength | ASTM D 2671 | ≥0.2MPa |
| Elongation at break | ASTM D 2671 | ≥1000% |
| Dielectric strength | IEC 243 | ≥15KV/mm |
| Peel strength | DIN 30672 | 10N/mm |
| Volume resistance | IEC 93 | ≥1.0×10¹⁴Ω•cm |
| Density | ASTM D 792 | 1.10±0.05g/cm³ |
| Code | Thickness(mm) | Width(mm) | Length(mm) | Standard packing |
|---|---|---|---|---|
| HB1510 | 3 | 50 | 3000 | 50pcs/carton |
*Other sizes and packing are available on request.
The product is supplied as rolls of specified dimensions. Recommend to store in the original packing, protected from moisture, dust, heat and sunlight.
