Suitable for screwing non-tension aluminum connections
Using CU-washers in humid areas and for pre-rounded sector shaped conductors
With CU eye in screw-on and markings for correct crimping
Aluminium barrel is filled by neutral grease and covered by cap
Material: CU≥99.9%, AL≥99.5%
Suitable for screwing non-tension aluminum connections
Using CU-washers in humid areas and for pre-rounded sector shaped conductors
With CU eye in screw-on and markings for correct crimping
Aluminium barrel is filled by neutral grease and covered by cap
Material: CU≥99.9%, AL≥99.5%
| Type | D±0.2 | d±0.2 | ر0.3 | W±0.2 | L |
|---|---|---|---|---|---|
| DTL-3-16 | 10 | 6.5 | 10.5 | 20 | 80 |
| DTL-3-25 | 12 | 7.5 | 10.5 | 20 | 80 |
| DTL-3-35 | 14 | 8.5 | 10.5 | 25 | 82 |
| DTL-3-50 | 16 | 10 | 10.5 | 27 | 87 |
| DTL-3-70 | 18 | 11.5 | 13 | 32 | 106 |
| DTL-3-95 | 16 | 13.5 | 13 | 35 | 106 |
| DTL-3-120 | 23 | 15 | 13 | 35 | 112 |
| DTL-3-150 | 25 | 16.5 | 13 | 35 | 125 |
| DTL-3-185 | 16 | 18.5 | 13 | 42 | 136 |
| DTL-3-240 | 20 | 21 | 17 | 46 | 140 |
| DTL-3-300 | 34 | 23.5 | 17 | 50 | 156 |
| DTL-3-400 | 38 | 26.5 | 17 | 58 | 170 |
| DTL-3-500 | 42 | 29 | 22.5 | 59 | 171 |
Specific product dimensions are subject to iteration. Please contact us for complete specifications. Customization are available.
